TP/SL Probability Heatmap

What It Shows

A color-coded matrix showing the probability of hitting Take-Profit before Stop-Loss for every combination of TP and SL values:

• X-axis: Stop-Loss distance

• Y-axis: Take-Profit distance

• Colors: Green = high probability of TP first, Red = low probability

• White diagonal line: 1:1 risk/reward ratio

• Contour labels: 30%, 50%, 70% probability lines

How to Read It

Color Interpretation:

• Bright green: >70% chance of hitting TP before SL

• Blue/green: ~50% chance (coin flip)

• Purple/dark: <30% chance (SL gets hit more often)

Position Analysis:

• Lower-left corner: Small TP, small SL - fast resolution, moderate probability

• Upper-left corner: Large TP, small SL - ambitious targets with tight stops (usually low probability)

• Lower-right corner: Small TP, large SL - high probability but poor reward

• Upper-right corner: Large TP, large SL - rarely resolved within horizon

How to Use This to Improve Trading

1. Find Your Win Rate Sweet Spot:

Follow the 50% contour line (where green meets red). This shows TP/SL combinations where you win exactly half the time. For profitability, you need either:

• Win rate >50% (be in the green zone), OR

• TP > SL by enough margin to overcome lower win rate

2. Validate Your Current Settings:

Find your current TP/SL combination on the heatmap. What probability does it show? If you're using TP=3, SL=2 but the heatmap shows only 40% probability, you may be setting unrealistic targets.

3. Optimize for Higher Probability:

If you want 60%+ win rate for psychological comfort, find TP/SL combinations in the bright green zone. Accept that this may mean smaller targets or wider stops.

4. Identify Impossible Combinations:

Dark red/purple areas represent TP/SL combinations that almost never work with your signal. If you're trying to achieve 5:1 reward/risk but the heatmap shows 10% probability, the data says this is unrealistic.

5. Above vs Below the Diagonal:

• Above diagonal (TP > SL): Favorable risk/reward but typically lower probability

• Below diagonal (SL > TP): Higher probability but unfavorable risk/reward

The key is finding the highest probability point that's still above the diagonal.
